This guide will help you to install and start ThingsBoard Professional Edition (PE) using Docker and Docker Compose on Linux or Mac OS. This guide covers standalone ThingsBoard PE installation. If you are looking for a cluster installation instruction, please visit cluster setup page.

Prerequisites

Step 1. Pull ThingsBoard PE Image

docker pull thingsboard/tb-pe:3.5.1PE

Step 2. Obtain the license key

We assume you have already chosen your subscription plan or decided to purchase a perpetual license. If not, please navigate to pricing page to select the best license option for your case and get your license. See How-to get pay-as-you-go subscription or How-to get perpetual license for more details.

Note: We will reference the license key you have obtained during this step as PUT_YOUR_LICENSE_SECRET_HERE later in this guide.

Step 3. Choose ThingsBoard queue service

ThingsBoard使用消息系统存储服务之间的通信，请正确选择队列？

内存适用于开发环境（开发）
Kafka 适用于生产环境（集群）
RabbitMQ 适用生产环境（单体）
AWS SQS 适用生产环境（AWS公有云）
Google发布/订阅 适用生产环境（Google公有云）
Azure服务总线 适用生产环境（Azure公有云）
Confluent云 适用于生产环境（托管）

参见相应的架构页面和规则引擎页面以获取更多详细信息。

In Memory (built-in and default)

AWS SQS (managed service from AWS)

Google Pub/Sub (managed service from Google)

Azure Service Bus (managed service from Azure)

RabbitMQ (for small on-prem installations)

Confluent Cloud (Event Streaming Platform based on Kafka)

ThingsBoard默认使用内存队列服务无需额外设置。

创建docker compose文件：

nano docker-compose.yml

Add the following line to the yml file. Don’t forget to replace “PUT_YOUR_LICENSE_SECRET_HERE” with your license secret obtained on the first step:

version: '3.0'
services:
  mytbpe:
    restart: always
    image: "thingsboard/tb-pe:3.5.1PE"
    ports:
      - "8080:8080"
      - "1883:1883"
      - "7070:7070"
      - "5683-5688:5683-5688/udp"
    environment:
      TB_QUEUE_TYPE: in-memory
      SPRING_DATASOURCE_URL: jdbc:postgresql://postgres:5432/thingsboard
      TB_LICENSE_SECRET: PUT_YOUR_LICENSE_SECRET_HERE
      TB_LICENSE_INSTANCE_DATA_FILE: /data/license.data
    volumes:
      - ~/.mytbpe-data:/data
      - ~/.mytbpe-logs:/var/log/thingsboard
  postgres:
    restart: always
    image: "postgres:12"
    ports:
    - "5432"
    environment:
      POSTGRES_DB: thingsboard
      POSTGRES_PASSWORD: postgres
    volumes:
      - ~/.mytbpe-data/db:/var/lib/postgresql/data

Apache Kafka是一个开源的流式数据处理平台。

创建docker compose文件：

nano docker-compose.yml

Add the following line to the yml file. Don’t forget to replace “PUT_YOUR_LICENSE_SECRET_HERE” with your license secret obtained on the first step:

version: '3.0'
services:
  zookeeper:
    restart: always
    image: "zookeeper:3.5"
    ports:
      - "2181:2181"
    environment:
      ZOO_MY_ID: 1
      ZOO_SERVERS: server.1=zookeeper:2888:3888;zookeeper:2181
  kafka:
    restart: always
    image: wurstmeister/kafka
    depends_on:
      - zookeeper
    ports:
      - "9092:9092"
    environment:
      KAFKA_ZOOKEEPER_CONNECT: zookeeper:2181
      KAFKA_LISTENERS: INSIDE://:9093,OUTSIDE://:9092
      KAFKA_ADVERTISED_LISTENERS: INSIDE://:9093,OUTSIDE://kafka:9092
      KAFKA_LISTENER_SECURITY_PROTOCOL_MAP: INSIDE:PLAINTEXT,OUTSIDE:PLAINTEXT
      KAFKA_INTER_BROKER_LISTENER_NAME: INSIDE
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock
  mytbpe:
    restart: always
    image: "thingsboard/tb-pe:3.5.1PE"
    depends_on:
      - kafka
    ports:
      - "8080:8080"
      - "1883:1883"
      - "7070:7070"
      - "5683-5688:5683-5688/udp"
    environment:
      TB_QUEUE_TYPE: kafka
      SPRING_DATASOURCE_URL: jdbc:postgresql://postgres:5432/thingsboard
      TB_KAFKA_SERVERS: kafka:9092
      TB_LICENSE_SECRET: PUT_YOUR_LICENSE_SECRET_HERE
      TB_LICENSE_INSTANCE_DATA_FILE: /data/license.data
    volumes:
      - ~/.mytbpe-data:/data
      - ~/.mytbpe-logs:/var/log/thingsboard
  postgres:
    restart: always
    image: "postgres:12"
    ports:
    - "5432"
    environment:
      POSTGRES_DB: thingsboard
      POSTGRES_PASSWORD: postgres
    volumes:
      - ~/.mytbpe-data/db:/var/lib/postgresql/data

AWS SQS配置

首先需要创建AWS账户然后访问AWS SQS服务。

使用此说明创建AWS SQS服务凭证。

Access key ID
Secret access key

创建docker compose文件：

nano docker-compose.yml

添加配置将”YOUR_KEY”和”YOUR_SECRET”替换为真实的AWS用户凭证并将”YOUR_REGION”替换成AWS SQS帐户区域：and “PUT_YOUR_LICENSE_SECRET_HERE” with your license secret obtained on the first step:

version: '3.0'
services:
  mytbpe:
    restart: always
    image: "thingsboard/tb-pe:3.5.1PE"
    ports:
      - "8080:8080"
      - "1883:1883"
      - "7070:7070"
      - "5683-5688:5683-5688/udp"
    environment:
      TB_QUEUE_TYPE: aws-sqs
      SPRING_DATASOURCE_URL: jdbc:postgresql://postgres:5432/thingsboard
      TB_QUEUE_AWS_SQS_ACCESS_KEY_ID: YOUR_KEY
      TB_QUEUE_AWS_SQS_SECRET_ACCESS_KEY: YOUR_SECRET
      TB_QUEUE_AWS_SQS_REGION: YOUR_REGION
      TB_LICENSE_SECRET: PUT_YOUR_LICENSE_SECRET_HERE
      TB_LICENSE_INSTANCE_DATA_FILE: /data/license.data

      # These params affect the number of requests per second from each partitions per each queue.
      # Number of requests to particular Message Queue is calculated based on the formula:
      # ((Number of Rule Engine and Core Queues) * (Number of partitions per Queue) + (Number of transport queues)
      #  + (Number of microservices) + (Number of JS executors)) * 1000 / POLL_INTERVAL_MS
      # For example, number of requests based on default parameters is:
      # Rule Engine queues:
      # Main 10 partitions + HighPriority 10 partitions + SequentialByOriginator 10 partitions = 30
      # Core queue 10 partitions
      # Transport request Queue + response Queue = 2
      # Rule Engine Transport notifications Queue + Core Transport notifications Queue = 2
      # Total = 44
      # Number of requests per second = 44 * 1000 / 25 = 1760 requests
      #
      # Based on the use case, you can compromise latency and decrease number of partitions/requests to the queue, if the message load is low.
      # By UI set the parameters - interval (1000) and partitions (1) for Rule Engine queues.
      # Sample parameters to fit into 10 requests per second on a "monolith" deployment:
      TB_QUEUE_CORE_POLL_INTERVAL_MS: 1000
      TB_QUEUE_CORE_PARTITIONS: 2
      TB_QUEUE_RULE_ENGINE_POLL_INTERVAL_MS: 1000
      TB_QUEUE_TRANSPORT_REQUEST_POLL_INTERVAL_MS: 1000
      TB_QUEUE_TRANSPORT_RESPONSE_POLL_INTERVAL_MS: 1000
      TB_QUEUE_TRANSPORT_NOTIFICATIONS_POLL_INTERVAL_MS: 1000
      TB_QUEUE_VC_INTERVAL_MS: 1000
      TB_QUEUE_VC_PARTITIONS: 1
    volumes:
      - ~/.mytbpe-data:/data
      - ~/.mytbpe-logs:/var/log/thingsboard
  postgres:
    restart: always
    image: "postgres:12"
    ports:
    - "5432"
    environment:
      POSTGRES_DB: thingsboard
      POSTGRES_PASSWORD: postgres
    volumes:
      - ~/.mytbpe-data/db:/var/lib/postgresql/data

可以使用UI更新默认规则引擎队列配置（轮询间隔和分区）有关ThingsBoard规则引擎队列的更多信息请参阅文档。

Google发布/订阅配置

创建一个Google帐户并访问发布/订阅服务。

使用此说明创建一个项目并使用发布/订阅服务。

使用此说明创建服务帐户凭据并编辑角色或管理员后保存json凭据步骤9的文件此处。

创建docker compose文件：

nano docker-compose.yml

添加下面配置内容使用真正用户密码替换“YOUR_PROJECT_ID”, “YOUR_SERVICE_ACCOUNT”：and “PUT_YOUR_LICENSE_SECRET_HERE” with your license secret obtained on the first step:

version: '3.0'
services:
  mytbpe:
    restart: always
    image: "thingsboard/tb-pe:3.5.1PE"
    ports:
      - "8080:8080"
      - "1883:1883"
      - "7070:7070"
      - "5683-5688:5683-5688/udp"
    environment:
      TB_QUEUE_TYPE: pubsub
      SPRING_DATASOURCE_URL: jdbc:postgresql://postgres:5432/thingsboard
      TB_QUEUE_PUBSUB_PROJECT_ID: YOUR_PROJECT_ID
      TB_QUEUE_PUBSUB_SERVICE_ACCOUNT: YOUR_SERVICE_ACCOUNT
      TB_LICENSE_SECRET: PUT_YOUR_LICENSE_SECRET_HERE
      TB_LICENSE_INSTANCE_DATA_FILE: /data/license.data

      # These params affect the number of requests per second from each partitions per each queue.
      # Number of requests to particular Message Queue is calculated based on the formula:
      # ((Number of Rule Engine and Core Queues) * (Number of partitions per Queue) + (Number of transport queues)
      #  + (Number of microservices) + (Number of JS executors)) * 1000 / POLL_INTERVAL_MS
      # For example, number of requests based on default parameters is:
      # Rule Engine queues:
      # Main 10 partitions + HighPriority 10 partitions + SequentialByOriginator 10 partitions = 30
      # Core queue 10 partitions
      # Transport request Queue + response Queue = 2
      # Rule Engine Transport notifications Queue + Core Transport notifications Queue = 2
      # Total = 44
      # Number of requests per second = 44 * 1000 / 25 = 1760 requests
      #
      # Based on the use case, you can compromise latency and decrease number of partitions/requests to the queue, if the message load is low.
      # By UI set the parameters - interval (1000) and partitions (1) for Rule Engine queues.
      # Sample parameters to fit into 10 requests per second on a "monolith" deployment:
      TB_QUEUE_CORE_POLL_INTERVAL_MS: 1000
      TB_QUEUE_CORE_PARTITIONS: 2
      TB_QUEUE_RULE_ENGINE_POLL_INTERVAL_MS: 1000
      TB_QUEUE_TRANSPORT_REQUEST_POLL_INTERVAL_MS: 1000
      TB_QUEUE_TRANSPORT_RESPONSE_POLL_INTERVAL_MS: 1000
      TB_QUEUE_TRANSPORT_NOTIFICATIONS_POLL_INTERVAL_MS: 1000
      TB_QUEUE_VC_INTERVAL_MS: 1000
      TB_QUEUE_VC_PARTITIONS: 1
    volumes:
      - ~/.mytbpe-data:/data
      - ~/.mytbpe-logs:/var/log/thingsboard
  postgres:
    restart: always
    image: "postgres:12"
    ports:
    - "5432"
    environment:
      POSTGRES_DB: thingsboard
      POSTGRES_PASSWORD: postgres
    volumes:
      - ~/.mytbpe-data/db:/var/lib/postgresql/data

可以使用UI更新默认规则引擎队列配置（轮询间隔和分区）有关ThingsBoard规则引擎队列的更多信息请参阅文档。

Azure服务总线配置

创建Azure帐户并访问Azure服务总线。

通过使用说明了解并使用总线服务。

使用说明创建共享访问签名。

创建docker compose文件：

nano docker-compose.yml

添加下面配置内容使用真正的服务总线名称空间替换”YOUR_NAMESPACE_NAME”和”YOUR_SAS_KEY_NAME”及”YOUR_SAS_KEY”：

version: '3.0'
services:
  mytbpe:
    restart: always
    image: "thingsboard/tb-pe:3.5.1PE"
    ports:
      - "8080:8080"
      - "1883:1883"
      - "7070:7070"
      - "5683-5688:5683-5688/udp"
    environment:
      TB_QUEUE_TYPE: service-bus
      SPRING_DATASOURCE_URL: jdbc:postgresql://postgres:5432/thingsboard
      TB_QUEUE_SERVICE_BUS_NAMESPACE_NAME: YOUR_NAMESPACE_NAME
      TB_QUEUE_SERVICE_BUS_SAS_KEY_NAME: YOUR_SAS_KEY_NAME
      TB_QUEUE_SERVICE_BUS_SAS_KEY: YOUR_SAS_KEY
      TB_LICENSE_SECRET: PUT_YOUR_LICENSE_SECRET_HERE
      TB_LICENSE_INSTANCE_DATA_FILE: /data/license.data

      # These params affect the number of requests per second from each partitions per each queue.
      # Number of requests to particular Message Queue is calculated based on the formula:
      # ((Number of Rule Engine and Core Queues) * (Number of partitions per Queue) + (Number of transport queues)
      #  + (Number of microservices) + (Number of JS executors)) * 1000 / POLL_INTERVAL_MS
      # For example, number of requests based on default parameters is:
      # Rule Engine queues:
      # Main 10 partitions + HighPriority 10 partitions + SequentialByOriginator 10 partitions = 30
      # Core queue 10 partitions
      # Transport request Queue + response Queue = 2
      # Rule Engine Transport notifications Queue + Core Transport notifications Queue = 2
      # Total = 44
      # Number of requests per second = 44 * 1000 / 25 = 1760 requests
      #
      # Based on the use case, you can compromise latency and decrease number of partitions/requests to the queue, if the message load is low.
      # By UI set the parameters - interval (1000) and partitions (1) for Rule Engine queues.
      # Sample parameters to fit into 10 requests per second on a "monolith" deployment:
      TB_QUEUE_CORE_POLL_INTERVAL_MS: 1000
      TB_QUEUE_CORE_PARTITIONS: 2
      TB_QUEUE_RULE_ENGINE_POLL_INTERVAL_MS: 1000
      TB_QUEUE_TRANSPORT_REQUEST_POLL_INTERVAL_MS: 1000
      TB_QUEUE_TRANSPORT_RESPONSE_POLL_INTERVAL_MS: 1000
      TB_QUEUE_TRANSPORT_NOTIFICATIONS_POLL_INTERVAL_MS: 1000
      TB_QUEUE_VC_INTERVAL_MS: 1000
      TB_QUEUE_VC_PARTITIONS: 1
    volumes:
      - ~/.mytbpe-data:/data
      - ~/.mytbpe-logs:/var/log/thingsboard
  postgres:
    restart: always
    image: "postgres:12"
    ports:
    - "5432"
    environment:
      POSTGRES_DB: thingsboard
      POSTGRES_PASSWORD: postgres
    volumes:
      - ~/.mytbpe-data/db:/var/lib/postgresql/data

可以使用UI更新默认规则引擎队列配置（轮询间隔和分区）有关ThingsBoard规则引擎队列的更多信息请参阅文档。

你可以使用官方文档安装RabbitMQ或按照以下说明：

创建docker compose文件：

nano docker-compose.yml

Add the following line to the yml file. Don’t forget to replace “YOUR_USERNAME” and “YOUR_PASSWORD” with your real user credentials, “localhost” and “5672” with your real RabbitMQ host and port, and “PUT_YOUR_LICENSE_SECRET_HERE” with your license secret obtained on the first step:

version: '3.0'
services:
  mytbpe:
    restart: always
    image: "thingsboard/tb-pe:3.5.1PE"
    ports:
      - "8080:8080"
      - "1883:1883"
      - "7070:7070"
      - "5683-5688:5683-5688/udp"
    environment:
      TB_QUEUE_TYPE: rabbitmq
      SPRING_DATASOURCE_URL: jdbc:postgresql://postgres:5432/thingsboard
      TB_QUEUE_RABBIT_MQ_USERNAME: YOUR_USERNAME
      TB_QUEUE_RABBIT_MQ_PASSWORD: YOUR_PASSWORD
      TB_QUEUE_RABBIT_MQ_HOST: localhost
      TB_QUEUE_RABBIT_MQ_PORT: 5672
      TB_LICENSE_SECRET: PUT_YOUR_LICENSE_SECRET_HERE
      TB_LICENSE_INSTANCE_DATA_FILE: /data/license.data
    volumes:
      - ~/.mytbpe-data:/data
      - ~/.mytbpe-logs:/var/log/thingsboard
  postgres:
    restart: always
    image: "postgres:12"
    ports:
    - "5432"
    environment:
      POSTGRES_DB: thingsboard
      POSTGRES_PASSWORD: postgres
    volumes:
      - ~/.mytbpe-data/db:/var/lib/postgresql/data

Confluent配置

你应该创建一个帐户后访问Confluent云然后创建一个Kafka集群和 API Key。

创建docker compose文件：

nano docker-compose.yml

添加下面配置内容使用真正的Confluent云服务器地址替换”CLUSTER_API_KEY”, “CLUSTER_API_SECRET”和”localhost:9092”：

version: '3.0'
services:
  mytbpe:
    restart: always
    image: "thingsboard/tb-pe:3.5.1PE"
    ports:
      - "8080:8080"
      - "1883:1883"
      - "7070:7070"
      - "5683-5688:5683-5688/udp"
    environment:
      TB_QUEUE_TYPE=kafka
      SPRING_DATASOURCE_URL: jdbc:postgresql://postgres:5432/thingsboard

      TB_KAFKA_SERVERS:confluent.cloud:9092
      TB_QUEUE_KAFKA_REPLICATION_FACTOR:3

      TB_QUEUE_KAFKA_USE_CONFLUENT_CLOUD:true
      TB_QUEUE_KAFKA_CONFLUENT_SSL_ALGORITHM:https
      TB_QUEUE_KAFKA_CONFLUENT_SASL_MECHANISM:PLAIN
      TB_QUEUE_KAFKA_CONFLUENT_SASL_JAAS_CONFIG:org.apache.kafka.common.security.plain.PlainLoginModule required username="CLUSTER_API_KEY" password="CLUSTER_API_SECRET";
      TB_QUEUE_KAFKA_CONFLUENT_SECURITY_PROTOCOL:SASL_SSL
      TB_QUEUE_KAFKA_CONFLUENT_USERNAME:CLUSTER_API_KEY
      TB_QUEUE_KAFKA_CONFLUENT_PASSWORD:CLUSTER_API_SECRET

      TB_QUEUE_KAFKA_RE_TOPIC_PROPERTIES:retention.ms:604800000;segment.bytes:52428800;retention.bytes:1048576000
      TB_QUEUE_KAFKA_CORE_TOPIC_PROPERTIES:retention.ms:604800000;segment.bytes:52428800;retention.bytes:1048576000
      TB_QUEUE_KAFKA_TA_TOPIC_PROPERTIES:retention.ms:604800000;segment.bytes:52428800;retention.bytes:1048576000
      TB_QUEUE_KAFKA_NOTIFICATIONS_TOPIC_PROPERTIES:retention.ms:604800000;segment.bytes:52428800;retention.bytes:1048576000
      TB_QUEUE_KAFKA_JE_TOPIC_PROPERTIES:retention.ms:604800000;segment.bytes:52428800;retention.bytes:104857600

      # These params affect the number of requests per second from each partitions per each queue.
      # Number of requests to particular Message Queue is calculated based on the formula:
      # ((Number of Rule Engine and Core Queues) * (Number of partitions per Queue) + (Number of transport queues)
      #  + (Number of microservices) + (Number of JS executors)) * 1000 / POLL_INTERVAL_MS
      # For example, number of requests based on default parameters is:
      # Rule Engine queues:
      # Main 10 partitions + HighPriority 10 partitions + SequentialByOriginator 10 partitions = 30
      # Core queue 10 partitions
      # Transport request Queue + response Queue = 2
      # Rule Engine Transport notifications Queue + Core Transport notifications Queue = 2
      # Total = 44
      # Number of requests per second = 44 * 1000 / 25 = 1760 requests
      #
      # Based on the use case, you can compromise latency and decrease number of partitions/requests to the queue, if the message load is low.
      # By UI set the parameters - interval (1000) and partitions (1) for Rule Engine queues.
      # Sample parameters to fit into 10 requests per second on a "monolith" deployment:
      TB_QUEUE_CORE_POLL_INTERVAL_MS: 1000
      TB_QUEUE_CORE_PARTITIONS: 2
      TB_QUEUE_RULE_ENGINE_POLL_INTERVAL_MS: 1000
      TB_QUEUE_TRANSPORT_REQUEST_POLL_INTERVAL_MS: 1000
      TB_QUEUE_TRANSPORT_RESPONSE_POLL_INTERVAL_MS: 1000
      TB_QUEUE_TRANSPORT_NOTIFICATIONS_POLL_INTERVAL_MS: 1000
      TB_QUEUE_VC_INTERVAL_MS: 1000
      TB_QUEUE_VC_PARTITIONS: 1
    volumes:
      - ~/.mytbpe-data:/data
      - ~/.mytbpe-logs:/var/log/thingsboard
  postgres:
    restart: always
    image: "postgres:12"
    ports:
    - "5432"
    environment:
      POSTGRES_DB: thingsboard
      POSTGRES_PASSWORD: postgres
    volumes:
      - ~/.mytbpe-data/db:/var/lib/postgresql/data

可以使用UI更新默认规则引擎队列配置（轮询间隔和分区）有关ThingsBoard规则引擎队列的更多信息请参阅文档。

Where:

PUT_YOUR_LICENSE_SECRET_HERE - placeholder for your license secret obtained on the third step;
8080:8080 - connect local port 8080 to exposed internal HTTP port 8080;
1883:1883 - connect local port 1883 to exposed internal MQTT port 1883;
7070:7070 - connect local port 7070 to exposed internal Edge RPC port 7070;
5683-5688:5683-5688/udp - connect local UDP ports 5683-5688 to exposed internal COAP and LwM2M ports;
~/.mytbpe-data:/data - mounts the host’s dir ~/.mytbpe-data to ThingsBoard data directory;
~/.mytbpe-data/db:/var/lib/postgresql/data - mounts the host’s dir ~/.mytbpe-data/db to Postgres data directory;
~/.mytbpe-logs:/var/log/thingsboard - mounts the host’s dir ~/.mytbpe-logs to ThingsBoard logs directory;
mytbpe - friendly local name of this machine;
restart: always - automatically start ThingsBoard in case of system reboot and restart in case of failure.;
thingsboard/tb-pe:3.5.1PE - docker image.

Step 4. Running

在启动Docker容器之前请运行以下命令以创建用于存储数据和日志的目录然后将其所有者更改为Docker容器用户，以便能够更改用户使用chown命令该命令需要sudo权限（该命令将要求sudo访问的密码）：

mkdir -p ~/.mytbpe-data && sudo chown -R 799:799 ~/.mytbpe-data
mkdir -p ~/.mytbpe-logs && sudo chown -R 799:799 ~/.mytbpe-logs

NOTE: replace directory ~/.mytbpe-data and ~/.mytbpe-logs with directories you’re planning to used in docker-compose.yml.

在包含该文件的目录终端中执行以下命令启动此docker compos：docker-compose.yml

docker compose pull
docker compose up -d
docker compose logs -f mytbpe

执行完命令后你可以http://{your-host-ip}:8080在浏览器中打开(例如http://localhost:9090)。使用以下默认凭据：

System Administrator: sysadmin@thingsboard.org / sysadmin
Tenant Administrator: tenant@thingsboard.org / tenant
Customer User: customer@thingsboard.org / customer

可以在帐户详情页面中更改每个帐户的密码。

Detaching, stop and start commands

你可以使用Ctrl-p Ctrl-q与会话终端分离容器将继续在后台运行。

如果出现任何问题可以检查服务日志中的错误例如：要查看ThingsBoard容器日志。
请执行以下命令：

docker compose logs -f mytbpe

停止容器：

docker compose stop mytbpe

启动容器：

docker compose start mytbpe

Troubleshooting

DNS issues

注意：如果你发现与DNS问题相关的错误，例如

127.0.1.1:53: cannot unmarshal DNS message

你可以将系统配置为使用 Google公共DNS服务器。
请参阅相应的Linux和Mac OS说明

Upgrading from old PostgreSQL 9.6 to PostgreSQL 11 and ThingsBoard 3.0.1PE

In this example we’ll show steps to upgrade ThingsBoard from 2.4.3PE to 3.0.1PE.

Make a backup of your data:

sudo cp -r ~/.mytbpe-data ./.mytbpe-data-2-4-3-backup

Stop currently running docker container:

docker stop [container_id]

Upgrade old postgres to the new one:

docker run --rm -v ~/.mytbpe-data/db/:/var/lib/postgresql/9.6/data -v ~/.mytbpe-data-temp/db/:/var/lib/postgresql/11/data --env LANG=C.UTF-8 tianon/postgres-upgrade:9.6-to-11
sudo rm -rf ~/.mytbpe-data/db
sudo mv ~/.mytbpe-data-temp/db ~/.mytbpe-data/db

Start the new version of TB with following command:

docker run -it -v ~/.mytbpe-data:/data --rm thingsboard/tb-pe:3.0.1PE bash

Then please follow these steps:

apt update
apt install sudo
chown -R postgres. /data/db/
chmod 750 -R /data/db/
sudo -i -u postgres
cd /usr/lib/postgresql/11/
./bin/pg_ctl -D /data/db start
logout
/usr/share/thingsboard/bin/install/upgrade.sh --fromVersion=2.4.1
exit

After this create your docker-compose.yml and insert (we used in-memory queue as an example):

version: '3.0'
services:
  mytbpe:
    restart: always
    image: "thingsboard/tb-pe:3.0.1PE"
    ports:
      - "8080:9090"
      - "1883:1883"
      - "7070:7070"
      - "5683-5688:5683-5688/udp"
    environment:
      TB_QUEUE_TYPE: in-memory
      TB_LICENSE_SECRET: YOUR_SECRET_KEY
      TB_LICENSE_INSTANCE_DATA_FILE: /data/license.data
      INTEGRATIONS_RPC_PORT: 50052
      PGDATA: /data/db
    volumes:
      - ~/.mytbpe-data:/data
      - ~/.mytbpe-logs:/var/log/thingsboard

Start ThingsBoard:

docker compose up

Upgrading from 3.0.1PE to 3.1.0PE

After 3.0.1PE PostgreSQL service was separated from ThingsBoard image and upgrading to 3.1.0PE version is not trivial.

First of all you need to create a dump of your database:

docker compose exec mytbpe sh -c "pg_dump -U postgres thingsboard > /data/thingsboard_dump"

Note You have to use your valid username for connecting to PostgreSQL

Then you need to stop service, create a new directory for the database and set permissions:

sudo cp -r ~/.mytbpe-data ./.mytbpe-data-backup
docker compose down
sudo rm -rf ~/.mytbpe-data/db
sudo chown -R 799:799 ~/.mytbpe-data
sudo chown -R 799:799 ~/.mytbpe-logs

After this you need to update docker-compose.yml as in Step 4 but with 3.1.0PE instead of 3.5.1PE:

Start PostgreSQL:

docker compose up postgres

Restore backup:

sudo cp ~/.mytbpe-data/thingsboard_dump ~/.mytbpe-data/db/thingsboard_dump
docker compose exec postgres sh -c "psql -U postgres thingsboard < /var/lib/postgresql/data/thingsboard_dump"

Upgrade ThingsBoard:

docker compose run mytbpe upgrade-tb.sh

Start ThingsBoard:

docker compose up mytbpe

Upgrade starting from 3.1.0PE

Please refer to the troubleshooting section in case you are upgrading from 3.0.0 or 3.0.1.

Below is example on how to upgrade from 3.1.0 to 3.1.1

Stop mytbpe container

docker compose stop mytbpe

Create a dump of your database:

docker compose exec postgres sh -c "pg_dump -U postgres thingsboard > /var/lib/postgresql/data/thingsboard_dump"

After this you need to update docker-compose.yml as in Step 4 but with 3.1.1PE instead of 3.2.2PE:
Change upgradeversion variable to your current ThingsBoard version.

sudo sh -c "echo '3.1.0' > ~/.mytbpe-data/.upgradeversion"

Then execute the following commands:

docker compose run mytbpe upgrade-tb.sh

Start ThingsBoard:

docker compose up -d

To upgrade ThingsBoard to the latest version those steps should be done for each intermediate version.

Please note that upgrades are not cumulative. Refer to upgrade instruction to know the right order of upgrades (e.g. if you are upgrading from 3.1.0 to 3.2.1, you need to do that in the following order: 3.1.0 -> 3.1.1 -> 3.2.0 -> 3.2.1, e.g. current version -> next release version -> etc)

In case you need to restore from the backup:

Stop mytbpe container

docker compose stop mytbpe

Update docker-compose.yml to the initial version.
Execute

docker compose exec postgres sh -c "psql -U postgres -c 'drop database thingsboard'"
docker compose exec postgres sh -c "psql -U postgres -c 'create database thingsboard'"
docker compose exec postgres sh -c "psql -U postgres thingsboard < /var/lib/postgresql/data/thingsboard_dump"

Start ThingsBoard:

docker compose up -d

If you need to copy backup to local directory in case restoring it on another server:

docker cp tb-docker_postgres_1:/var/lib/postgresql/data/thingsboard_dump .

Note: You should paste the name for your postgres container.

Next steps

入门指南 - 快速学习ThingsBoard相关功能。
连接设备 - 学习如何根据你的连接方式或解决方案连接设备。
可视化 - 学习如何配置复杂的ThingsBoard仪表板说明。
数据处理 - 学习如何使用ThingsBoard规则引擎。
数据分析 - 学习如何使用规则引擎执行基本的分析任务。
硬件样品 - 学习如何将各种硬件平台连接到ThingsBoard。
高级功能 - 学习高级ThingsBoard功能。
开发指南 - 学习ThingsBoard中的贡献和开发。

本页目录

Installing ThingsBoard PE using Docker (Linux or Mac OS)

Prerequisites

Step 1. Pull ThingsBoard PE Image

Step 2. Obtain the license key

Step 3. Choose ThingsBoard queue service

AWS SQS配置

Google发布/订阅配置

Azure服务总线配置

Confluent配置

Step 4. Running

Detaching, stop and start commands

Troubleshooting

DNS issues

Upgrading from old PostgreSQL 9.6 to PostgreSQL 11 and ThingsBoard 3.0.1PE

Upgrading from 3.0.1PE to 3.1.0PE

Upgrade starting from 3.1.0PE

Next steps
